RK Model
DAIN
| Product Model | DYRK3500 | |
| Standard Model | 2.5kW | |
| Rated Voltage (V) | 220/380 | |
| Rated Output Power (kW) COP | 2.5 | |
| Maximum Output Power (kW) | 2.7 | |
| Rated Current (A) | 11/4.5 | |
| Rated Frequency (Hz) | 50Hz | |
| Power Factor | 1/0.8 | |
| Fuel Tank Capacity (L) | 15 | |
| Theoretical Operating Time (h) | 6~7 | |
| Operating Altitude (m) | ≤1000m | |
| Operating Ambient Temperature (℃) | ≤40℃ | |
| Phase | Single Phase | |
| Engine Model | 170FA | |
| Engine Displacement (cc) | 210 | |
| Bore × Stroke (mm) | 70×55 | |
| Rated Speed (r/min) | 3000/3600rpm (Selectable) | |
| Ignition System | Contactless Transistor Ignition | |
| Starting Method | Recoil Start / Electric Start (Selectable) | |
| Cooling System | Forced Air Cooling | |
| Engine oil Capacity (L) | 0.6 | |
| Fuel Consumption (g/(kW·h)) | ≤370 | |
| Accessory Configuration | Wheels + Handle (Optional) | |
| Product Dimensions (mm) | 590×455×440 | |
| Packaging Dimensions (mm) | 600×465×455 | |
| Net Weight/Gross Weight (kg) | Manual Start | 36/39 |
| Electric Start | 40/43 | |
| Weight with Wheels & Handle | 2.5 | |
| Quantity per 40ft High Cube Container | 490 | |
| Product Model | DYRK3500 | |
| Standard Model | 2.5kW | |
| Rated Voltage (V) | 220/380 | |
| Rated Output Power (kW) COP | 2.5 | |
| Maximum Output Power (kW) | 2.7 | |
| Rated Current (A) | 11/4.5 | |
| Rated Frequency (Hz) | 50Hz | |
| Power Factor | 1/0.8 | |
| Fuel Tank Capacity (L) | 15 | |
| Theoretical Operating Time (h) | 6~7 | |
| Operating Altitude (m) | ≤1000m | |
| Operating Ambient Temperature (℃) | ≤40℃ | |
| Phase | Single Phase | |
| Engine Model | 170FA | |
| Engine Displacement (cc) | 210 | |
| Bore × Stroke (mm) | 70×55 | |
| Rated Speed (r/min) | 3000/3600rpm (Selectable) | |
| Ignition System | Contactless Transistor Ignition | |
| Starting Method | Recoil Start / Electric Start (Selectable) | |
| Cooling System | Forced Air Cooling | |
| Engine oil Capacity (L) | 0.6 | |
| Fuel Consumption (g/(kW·h)) | ≤370 | |
| Accessory Configuration | Wheels + Handle (Optional) | |
| Product Dimensions (mm) | 590×455×440 | |
| Packaging Dimensions (mm) | 600×465×455 | |
| Net Weight/Gross Weight (kg) | Manual Start | 36/39 |
| Electric Start | 40/43 | |
| Weight with Wheels & Handle | 2.5 | |
| Quantity per 40ft High Cube Container | 490 | |
