KT Model
DAIN
| Product Model | DY250A-4.0 | DY300A-5.0 | |
| Standard Model | DY250A-4.0 | DY300A-5.0 | |
| Welding Electrode Diameter (mm) | 1.6-4.0mm (Continuous Welding for 4.0mm) | 1.6-5.0mm (Continuous Welding for 5.0mm) | |
| Maximum Welding Current | 250A | 300A | |
| Current Adjustment Method | - | - | |
| No-Load Voltage (V) | 50-60 | 20-60 | |
| Load Voltage (V) | 25-35 | ||
| Duty Cycle | 60% | ||
| Insulation Class | F | ||
| Rated Voltage (V) | 230 | ||
| Rated Output Power (kW) COP | 2.5 | ||
| Maximum Output Power (kW) | 2.8 | ||
| Rated Current (A) | 10.5 | ||
| Rated Frequency (Hz) | 50/60Hz (Optional) | ||
| Power Factor | 1 | ||
| Fuel Tank Capacity (L) | 6.5 | ||
| Theoretical Operating Time (h) | 2~2.5 | 1.5~2 | |
| Operating Altitude (m) | ≤1000m | ||
| Operating Ambient Temperature (℃) | ≤40℃ | ||
| Phase | Single Phase | ||
| Engine Model | 190F | 192FB | |
| Engine Displacement (cc) | 420 | 465 | |
| Bore × Stroke (mm) | 90×66 | 92×70 | |
| Rated Speed (r/min) | 3600 | ||
| Ignition System | Contactless Transistor Ignition | ||
| Starting Method | Recoil Start / Electric Start (Optional) | ||
| Cooling System | Forced Air Cooling | ||
| Engine oil Capacity (L) | 1.1 | ||
| Fuel Consumption (g/(kW·h)) | ≤370 | ||
| Accessory Configuration | Wheels (Optional) | ||
| Product Dimensions (mm) | 650×520×535 | ||
| Packaging Dimensions (mm) | 660×530×550 | ||
| Net Weight/Gross Weight (kg) | Manual Start | 64.2/69.3 | |
| Electric Start | - | ||
| Weight with Wheels | 2 | ||
| Quantity per 40ft High Cube Container | 304 | ||
