KB model
DAIN
| Product Model | DYKB3000I | DYKB3500I | DYKB4000I | DYKB4500I | DYKB5000I | DYKB5500I | DYKB6000I | |
| Standard Model | 2.0kW | 2.5kW | 3.0kW | 3.5kW | 4.0kW | 4.5kW | 5.0kW | |
| Rated Voltage (V) | 230 | |||||||
| Rated Frequency (Hz) | 50/60Hz (Optional) | |||||||
| Rated Output Power (kW) COP | 2 | 2.5 | 2.8 | 3.5 | 3.8 | 4.5 | 5 | |
| Maximum Output Power (kW) | 2.3 | 2.8 | 3 | 3.8 | 4 | 4.8 | 5.2 | |
| Rated Current (A) | 8.5 | 10.5 | 12 | 15 | 16.5 | 19.5 | 21.5 | |
| Power Factor | 1 | |||||||
| Fuel Tank Capacity (L) | 7 | |||||||
| Theoretical Operating Time (h) | 4~4.5 | 4~4.5 | 4~4.5 | 4~4.5 | 3~3.5 | 3~3.5 | 3~3.5 | |
| Operating Altitude (m) | ≤1000m | |||||||
| Operating Ambient Temperature (℃) | ≤40℃ | |||||||
| Phase | Single Phase | |||||||
| Engine Model | 170FA | 170FA | 170FA | 170FA | 172FB | 172FA | 172FA | |
| Engine Displacement (cc) | 210 | 210 | 210 | 210 | 230 | 230 | 230 | |
| Bore × Stroke (mm) | 70×55 | 70×55 | 70×55 | 70×55 | 72×58 | 72×58 | 72×58 | |
| Rated Speed (r/min) | 3600 | |||||||
| Ignition System | Contactless Transistor Ignition | |||||||
| Starting Method | Recoil Start / Electric Start (Optional) | |||||||
| Cooling System | Forced Air Cooling | |||||||
| Engine oil Capacity (L) | 0.65 | 0.65/0.7 | ||||||
| Fuel Consumption (g/(kW·h)) | ≤375 | ≤375 | ≤375 | ≤375 | ≤375 | ≤375 | ≤375 | |
| Accessory Configuration | Standard Accessories | |||||||
| Product Dimensions (mm) | 485×330×475 | |||||||
| Packaging Dimensions (mm) | 505×350×500 | |||||||
| Net Weight/Gross Weight (kg) | Manual Start | 24/26 | 24/26 | 25/27 | 25/27 | 27/29 | 28/30 | 28/30 |
| Electric Start | - | |||||||
| Weight with Wheels & Handle | - | |||||||
| Quantity per 40ft High Cube Container | 750 | |||||||
| Product Model | DYKB3000I | DYKB3500I | DYKB4000I | DYKB4500I | DYKB5000I | DYKB5500I | DYKB6000I | |
| Standard Model | 2.0kW | 2.5kW | 3.0kW | 3.5kW | 4.0kW | 4.5kW | 5.0kW | |
| Rated Voltage (V) | 230 | |||||||
| Rated Frequency (Hz) | 50/60Hz (Optional) | |||||||
| Rated Output Power (kW) COP | 2 | 2.5 | 2.8 | 3.5 | 3.8 | 4.5 | 5 | |
| Maximum Output Power (kW) | 2.3 | 2.8 | 3 | 3.8 | 4 | 4.8 | 5.2 | |
| Rated Current (A) | 8.5 | 10.5 | 12 | 15 | 16.5 | 19.5 | 21.5 | |
| Power Factor | 1 | |||||||
| Fuel Tank Capacity (L) | 7 | |||||||
| Theoretical Operating Time (h) | 4~4.5 | 4~4.5 | 4~4.5 | 4~4.5 | 3~3.5 | 3~3.5 | 3~3.5 | |
| Operating Altitude (m) | ≤1000m | |||||||
| Operating Ambient Temperature (℃) | ≤40℃ | |||||||
| Phase | Single Phase | |||||||
| Engine Model | 170FA | 170FA | 170FA | 170FA | 172FB | 172FA | 172FA | |
| Engine Displacement (cc) | 210 | 210 | 210 | 210 | 230 | 230 | 230 | |
| Bore × Stroke (mm) | 70×55 | 70×55 | 70×55 | 70×55 | 72×58 | 72×58 | 72×58 | |
| Rated Speed (r/min) | 3600 | |||||||
| Ignition System | Contactless Transistor Ignition | |||||||
| Starting Method | Recoil Start / Electric Start (Optional) | |||||||
| Cooling System | Forced Air Cooling | |||||||
| Engine oil Capacity (L) | 0.65 | 0.65/0.7 | ||||||
| Fuel Consumption (g/(kW·h)) | ≤375 | ≤375 | ≤375 | ≤375 | ≤375 | ≤375 | ≤375 | |
| Accessory Configuration | Standard Accessories | |||||||
| Product Dimensions (mm) | 485×330×475 | |||||||
| Packaging Dimensions (mm) | 505×350×500 | |||||||
| Net Weight/Gross Weight (kg) | Manual Start | 24/26 | 24/26 | 25/27 | 25/27 | 27/29 | 28/30 | 28/30 |
| Electric Start | - | |||||||
| Weight with Wheels & Handle | - | |||||||
| Quantity per 40ft High Cube Container | 750 | |||||||
