| Quantity: | |
|---|---|
| Product Model | DY5000iW-3.2 | DY5500iW-3.2 | |
| Standard Model | DY5000iW-3.2 | DY5500iW-3.2 | |
| Welding Electrode Diameter (mm) | 1.6-4.0mm (Continuous Welding for 3.2mm) | ||
| Current Adjustment Range | 60-160A | ||
| Current Adjustment Method | Manual Rotary Adjustment | ||
| No-Load Voltage (V) | 50-60 | ||
| Load Voltage (V) | 25-35 | ||
| Duty Cycle | 60% | ||
| Insulation Class | F | ||
| Rated Voltage (V) | 230 | ||
| Rated Frequency (Hz) | 50/60Hz (Optional) | ||
| Rated Output Power (kW) COP | 4 | 4.5 | |
| Maximum Output Power (kW) | 4.5 | 5 | |
| Rated Current (A) | 17 | 19.5 | |
| Power Factor | 1 | ||
| Fuel Tank Capacity (L) | 14 | ||
| Theoretical Operating Time (h) | 6~6.5 | ||
| Operating Altitude (m) | ≤1000m | ||
| Operating Ambient Temperature (℃) | ≤40℃ | ||
| Phase | Single Phase | ||
| Engine Model | 170FB | 172FA | |
| Engine Displacement (cc) | 225 | 230 | |
| Bore × Stroke (mm) | 70×58 | 72×58 | |
| Rated Speed (r/min) | 3600 | ||
| Ignition System | Contactless Transistor Ignition | ||
| Starting Method | Recoil Start / Electric Start (Optional) | ||
| Cooling System | Forced Air Cooling | ||
| Engine oil Capacity (L) | 0.65 | ||
| Fuel Consumption (g/(kW·h)) | ≤370 | ||
| Accessory Configuration | Standard Accessories | ||
| Product Dimensions (mm) | 530×430×445 | ||
| Packaging Dimensions (mm) | 540×440×460 | ||
| Net Weight/Gross Weight (kg) | Manual Start | 36/38.2 | |
| Electric Start | - | ||
| Weight with Wheels & Handle | - | ||
| Quantity per 40ft High Cube Container | 575 | ||
