H model
DAIN
| Product Model | DYH3000I | DYH3500I | DYH4000I | DYH4500I | DYH5000I | DYH5500I | |
| Standard Model | 2.0kW | 2.5kW | 3.0kW | 3.5kW | 4.0kW | 4.5kW | |
| Rated Voltage (V) | 230 | 230 | 230 | 230 | 230 | 230 | |
| Rated Frequency (Hz) | 50/60Hz (Optional) | ||||||
| Rated Output Power (kW) COP | 2 | 2.5 | 3 | 3.5 | 4 | 4.5 | |
| Maximum Output Power (kW) | 2.3 | 2.8 | 3.3 | 3.8 | 4.5 | 4.8 | |
| Rated Current (A) | 8.5 | 10.5 | 12.5 | 15 | 17 | 19.5 | |
| Power Factor | 1 | ||||||
| Fuel Tank Capacity (L) | 14 | ||||||
| Theoretical Operating Time (h) | 7~7.5 | 7~7.5 | 6~6.5 | 6~6.5 | 6~6.5 | 6~6.5 | |
| Operating Altitude (m) | ≤1000m | ||||||
| Operating Ambient Temperature (℃) | ≤40℃ | ||||||
| Phase | Single Phase | ||||||
| Engine Model | 170FA | 170FA | 170FB | 170FB | 170FB | 172FA | |
| Engine Displacement (cc) | 210 | 210 | 225 | 225 | 225 | 230 | |
| Bore × Stroke (mm) | 70×55 | 70×55 | 70×58 | 70×58 | 70×58 | 72×58 | |
| Rated Speed (r/min) | 3600 | ||||||
| Ignition System | Contactless Transistor Ignition | ||||||
| Starting Method | Recoil/Electric Start (Optional) | ||||||
| Cooling System | Forced Air Cooling | ||||||
| Engine oil Capacity (L) | 0.65 | ||||||
| Fuel Consumption (g/(kW·h)) | ≤370 | ||||||
| Accessory Configuration | Standard Accessories | ||||||
| Product Dimensions (mm) | 530×430×445 | ||||||
| Packaging Dimensions (mm) | 540×440×460 | ||||||
| Net Weight/Gross Weight (kg) | Manual Start | 32/34 | 32/34 | ||||
| Electric Start | - | ||||||
| Weight with Wheels & Handle | - | ||||||
| Quantity per 40ft High Cube Container | 575 | ||||||
