DAIN
| Product Model | 10000E | 10000E/SE | 12000E | 12000E/SE | 15000E | 15000E/SE | 18000E | 18000E/SE | |
| Standard Model | 8.0kW | 10kW | 12kW | 15kW | |||||
| Rated Voltage (V) | 220 | 220/380 | 220 | 220/380 | 220 | 220/380 | 220 | 220/380 | |
| Rated Output Power (kW) COP | 8 | 10 | 12 | 15 | |||||
| Maximum Output Power (kW) | 8.5 | 11 | 13 | 16.5 | |||||
| Rated Current (A) | 36 | 36/15 | 45.5 | 45.5/19 | 54.5 | 54.5/22.5 | 68 | 68/28.5 | |
| Rated Frequency (Hz) | 50/60Hz (Optional) | ||||||||
| Power Factor | 1.0/0.8 | ||||||||
| Fuel Tank Capacity (L) | 32 | ||||||||
| Theoretical Operating Time (h) | 5~5.5 | 5~5.5 | 5~5.5 | 5~5.5 | 4~4.5 | 4~4.5 | 3.5~4.0 | 3.5~4.0 | |
| Operating Altitude (m) | ≤1000 | ||||||||
| Operating Ambient Temperature (℃) | ≤40 | ||||||||
| Phase | Single Phase / Three Phase / Equal Power with Dual Voltage Integration (Optional) | ||||||||
| Engine Model | 2V78 | 2V78 | 2V80 | 2V90 | |||||
| Engine Displacement (cc) | 614 | 614 | 764 | 999 | |||||
| Bore × Stroke (mm) | 78×72 | 78×72 | 80×76 | 90×78.5 | |||||
| Rated Speed (r/min) | 3000/3600rpm (Optional) | ||||||||
| Ignition System | Contactless Transistor Ignition | ||||||||
| Starting Method | Electric Start | ||||||||
| Cooling System | Forced Air Cooling | ||||||||
| Engine oil Capacity (L) | 2 | ||||||||
| Fuel Consumption (g/(kW·h)) | ≤370 | ||||||||
| Accessory Configuration | 2 Fixed Wheels + 2 Swivel Wheels (Optional) | ||||||||
| Product Dimensions (mm) | 720×530×740 | 800×610×840 | |||||||
| Packaging Dimensions (mm) | 740×550×770 | 820×630×870 | |||||||
| Net Weight/Gross Weight (kg) | Electric Start | 92/99 | 95/102 | 132/139 | 135/142 | 180/187 | 183/190 | 193/200 | 200/207 |
| Weight with Wheels & Handle | 3 | 3 | |||||||
| Quantity per 40ft High Cube Container | 189 | 150 | |||||||
