| Product Model | DYKB-2-4000IW | DYKB-2-4500IW | DYKB-2-5000IW | DYKB-2-5500IW | |
| Standard Model | 3.0kW | 2.5kW | 2.0kW | 1.0kW | |
| Welding Electrode Diameter (mm) | 1.6-3.2mm | ||||
| Welding Current | 80-150A | ||||
| Current Adjustment Method | Manual Rotary Adjustment | ||||
| No-Load Voltage (V) | 50-60 | ||||
| Load Voltage (V) | 25-35 | ||||
| Duty Cycle | 60% | ||||
| Insulation Class | F | ||||
| Rated Voltage (V) | 230 | ||||
| Rated Frequency (Hz) | 50/60Hz (Optional) | ||||
| Rated Output Power (kW) COP | 3 | 2.5 | 2 | 1 | |
| Maximum Output Power (kW) | 3.3 | 2.8 | 2.3 | 1.2 | |
| Rated Current (A) | 13 | 10.5 | 8.5 | 4.3 | |
| Power Factor | 1 | ||||
| Fuel Tank Capacity (L) | 7 | ||||
| Theoretical Operating Time (h) | 4~4.5 | 4~4.5 | 3~3.5 | 3~3.5 | |
| Operating Altitude (m) | ≤1000m | ||||
| Operating Ambient Temperature (℃) | ≤40℃ | ||||
| Phase | Single Phase | ||||
| Engine Model | 170FB | 170FB | 172FB | 172FA | |
| Engine Displacement (cc) | 225 | 225 | 230 | 230 | |
| Bore × Stroke (mm) | 70×58 | 70×58 | 72×58 | 72×58 | |
| Rated Speed (r/min) | 4000 | ||||
| Ignition System | Contactless Transistor Ignition | ||||
| Starting Method | Recoil/Electric Start (Optional) | ||||
| Cooling System | Forced Air Cooling | ||||
| Engine oil Capacity (L) | 0.65 | 0.65 | 0.7 | 0.7 | |
| Fuel Consumption (g/(kW·h)) | ≤370 | ||||
| Accessory Configuration | Standard Accessories | ||||
| Product Dimensions (mm) | 485×330×485 | ||||
| Packaging Dimensions (mm) | 505×350×510 | ||||
| Net Weight/Gross Weight (kg) | Manual Start | 25.5/27 | 26/27.5 | 27/28.5 | 27/28.5 |
| Electric Start | - | ||||
| Weight with Wheels & Handle | - | ||||
| Quantity per 40ft High Cube Container | 750 | ||||
