DAIN
| Product Model | DYH12000SE | DYH12000SED | DYH15000SE | DYH15000SED | DYH18000SE | DYH185000SED | |
| Standard Model | 10kW | 12kW | 15kW | ||||
| Rated Voltage (V) | 220/230 | 220/380 230/400 | 220/380 | 220/380 230/400 | 220/380 | 220/380 230/400 | |
| Rated Output Power (kW) COP | 10 | 12 | 15 | ||||
| Maximum Output Power (kW) | 11 | 13 | 16 | ||||
| Rated Current (A) | 45/43 | 45/19 43/18 | 54.5/52 | 54.5/22.5 52/21.5 | 68/65 | 68/28 52/27 | |
| Rated Frequency (Hz) | 50 | ||||||
| Power Factor | 1 | 1/0.8 | 1 | 1/0.8 | 1 | 1/0.8 | |
| Phase | Single Phase | Single Phase / Three Phase / Equal Power | Single Phase | Single Phase / Three Phase / Equal Power | Single Phase | Single Phase / Three Phase / Equal Power | |
| Fuel Tank Capacity (L) | 25 | ||||||
| Theoretical Operating Time (h) | 7 | 6 | |||||
| Operating Altitude (m) | ≤1000 | ||||||
| Operating Ambient Temperature (℃) | ≤40 | ||||||
| Engine Model | 2V88F | 2V88F | 2V92F | 2V92F | 2V95F | 2V95F | |
| Engine Displacement (cc) | 870 | 870 | 997 | 997 | 1247 | 1247 | |
| Bore × Stroke (mm) | 88×75 | 88×75 | 92×75 | 92×75 | 98×88 | 98×88 | |
| Rated Speed (r/min) | 3000 | ||||||
| Combustion Method | Compression-ignition direct injection | ||||||
| Fuel supply advance angle (degree) | 20±1 BTDC (Before Top Dead Center) | ||||||
| Starting Method | Electric Start | ||||||
| Valve Clearance (Cold State) (mm) | 0.1-0.15 | ||||||
| Cooling System | Forced Air Cooling | ||||||
| Engine oil Capacity (L) | 3 | ||||||
| Fuel Consumption (g/(kW·h)) | ≤260 | ||||||
| Accessory Configuration | 2 Fixed Wheels + 2 Swivel Wheels | ||||||
| Product Dimensions (mm) | 1270×670×765 | 1270×670×765 | 1270×670×765 | 1270×670×765 | |||
| Packaging Dimensions (mm) | 1290×690×925 | 1290×690×925 | 1290×690×925 | 1290×690×925 | |||
| Net Weight/Gross Weight (kg) | Electric Start | 260 | 270 | ||||
| Weight with Wheels | 3 | 3 | 3 | 3 | |||
| Quantity per 40ft High Cube Container | 54 | 54 | 54 | 54 | |||
