DAIN
| Product Model | DY6500E/SE | DY8500E/SE | DY10000E/SE | |
| Standard Model | 5.0kW | 6.5kW | 8.0kW | |
| Rated Voltage (V) | 220/380 | |||
| Rated Output Power (kW) COP | 5 | 6 | 8 | |
| Maximum Output Power (kW) | 5.5 | 6.5 | 8.5 | |
| Rated Current (A) | 22.5/9 | 27/11 | 36/15 | |
| Rated Frequency (Hz) | 50/60Hz selectable | |||
| Power Factor | 1.0/0.8 | |||
| Fuel Tank Capacity (L) | 25 | |||
| Theoretical Operating Time (h) | 5.5~6 | 5.5~6 | 5.5~6 | |
| Operating Altitude (m) | ≤1000m | |||
| Operating Ambient Temperature (℃) | ≤40℃ | |||
| Number of Phases | Single-phase/Three-phase/Equal power | |||
| Engine Model | 190F | 190F | 192FB | |
| Engine Displacement (cc) | 420 | 420 | 465 | |
| Bore × Stroke (mm) | 90×66 | 90×66 | 92×70 | |
| Rated Speed (r/min) | 3000/3600rpm selectable | |||
| Combustion Method | Contactless Transistor Ignition | |||
| Starting Method | Electric start optional | |||
| Cooling Method | Forced air cooling | |||
| Engine oil Capacity (L) | 1.1 | |||
| Fuel Consumption (g/(kW·h)) | ≤370 | |||
| Accessory Configuration | Wheels + standard accessories | |||
| Product Dimensions (mm) | 940×540×730 | |||
| Packaging Dimensions (mm) | 960×560×760 | |||
| Net Weight/Gross Weight (kg) | Manual Start | - | - | - |
| Electric Start | 95/100 | 110/115 | 120/125 | |
| Weight with Wheels & Handle | 3 | |||
| Quantity per 40ft High Cube Container | 144 | |||
