DAIN
| Product Model | DYH9000SE | DYH10000SE | DYH13500E-S | DYH14500E-S | DYH15500E-S | |
| Standard Model | 5KW | 6KW | 7kW | 8kW | 9KW | |
| Rated Voltage (V) | 220/380 | |||||
| Rated Output Power (kW) COP | 5 | 6 | 7 | 8 | 9 | |
| Maximum Output Power (kW) | 5.5 | 6.5 | 7.5 | 8.5 | 9.5 | |
| Rated Current (A) | 22.5/9.5 | 27/11 | 31.5 | 36 | 40.5/17 | |
| Rated Frequency (Hz) | 50/60HZ optional | |||||
| Power Factor | 1.0/0.8 | |||||
| Phase | Single Phase | |||||
| Fuel Tank Capacity (L) | 12 | 12 | 12 | 12 | 12 | |
| Theoretical Operating Time (h) | 6-6.5 | 5-5.5 | 5-5.5 | 5-5.5 | 4-4.5 | |
| Operating Altitude (m) | ≤1000 | |||||
| Operating Ambient Temperature (℃) | ≤40 | |||||
| Engine Model | C188FE | C192FE | C195FE | C198FE | C110SFE | |
| Engine Displacement (cc) | 456 | 499 | 532 | 633 | 736 | |
| Bore × Stroke (mm) | 88×75 | 92×75 | 95×75 | 98×84 | 105×85 | |
| Rated Speed (r/min) | 3000/3600 optional | |||||
| Combustion Method | Compression-ignition direct injection | |||||
| Fuel supply advance angle (degree) | 20±1 BTDC (Before Top Dead Center) | |||||
| Starting Method | Electric Start | |||||
| Valve Clearance (Cold State) (mm) | 0.15±0.05 | |||||
| Cooling System | Forced Air Cooling | |||||
| Engine oil Capacity (L) | 1.65 | 1.65 | 1.65 | 2 | 2 | |
| Fuel Consumption (g/(kW·h)) | ≤275 | ≤275 | ≤265 | ≤260 | ≤260 | |
| Accessory Configuration | 2 Fixed Wheels + 2 Swivel Wheels | |||||
| Product Dimensions (mm) | 980×560×690 | 1080×600×750 | ||||
| Packaging Dimensions (mm) | 1030×620×830 | 1130×660×890 | ||||
| Net Weight/Gross Weight (kg) | Electric Start | 112/120 | 115/123 | 117/125 | 123/131 | 132/140 |
| Weight with Wheels | 3 | |||||
| Quantity per 40ft High Cube Container | 126 | 126 | 126 | 68 | 68 | |
