| Quantity: | |
|---|---|
DAIN
| Product Model | DY2500IS | DY3500IS | DY4500IS | |
| Standard Model | 2.0kW | 2.5kW | 3.0kW | |
| Rated Voltage (V) | 230 | |||
| Rated Output Power (kW) COP | 2 | 2.5 | 3 | |
| Maximum Output Power (kW) | 2.2 | 2.8 | 3.3 | |
| Rated Current (A) | 8.5 | 10.5 | 13 | |
| Rated Frequency (Hz) | 50Hz | |||
| Power Factor | 1 | |||
| Fuel Tank Capacity (L) | 4.1 | |||
| Theoretical Operating Time (h) | 4~5 | 3~4 | 3~4 | |
| Operating Altitude (m) | ≤1000m | |||
| Operating Ambient Temperature (℃) | ≤40℃ | |||
| Number of Phases | Single-phase | |||
| Engine Model | 154F | 164F | 164FB | |
| Engine Displacement (cc) | 80 | 145 | 145 | |
| Bore × Stroke (mm) | 54×38 | 64×45 | 64×45 | |
| Rated Speed (r/min) | 3000/3600rpm selectable | |||
| Combustion Method | Contactless Transistor Ignition | |||
| Starting Method | Manual start/Electric start optional | |||
| Cooling Method | Forced air cooling | |||
| Engine oil Capacity (L) | 0.35 | |||
| Fuel Consumption (g/(kW·h)) | ≤370 | |||
| Noise Limit (dB(A)/7m) | 55 | |||
| Accessory Configuration | Wheels + standard accessories | |||
| Product Dimensions (mm) | 485×280×435 | |||
| Packaging Dimensions (mm) | 570×370×475 | |||
| Net Weight/Gross Weight (kg) | Manual Weight | 18 | 23 | 23 |
| Electric Weight | - | |||
| Quantity per 40ft High Cube Container | 640 | |||
